What differential pinion shims actually do
In one sentence: the precision steel shim placed between the pinion gear head and the inner pinion bearing to set pinion depth and gear mesh pattern. When they wear out, you'll typically feel it before you see it — your car starts telling you something is wrong, and ignoring it gets expensive.
Signs you need new differential pinion shims
- incorrect ring-and-pinion mesh pattern after a rebuild
- differential whine on coast or drive after gear swap
- wear pattern shifted too far from the gear root or toe
- missing or damaged shim during teardown
- thicker or thinner shim required to dial in pattern
If you tick more than one box, replace before it leaves you on the side of the road. The repair gets a lot cheaper when you catch it early.
Also known as
Depending on the shop manual, region, or supplier you're reading, differential pinion shims are also called: pinion depth shim, pinion shim, drive pinion shim, gear depth shim, differential shim. They all refer to the same component — when you're cross-referencing OEM and aftermarket part numbers, watch for these naming variations so you don't double-order the same item.
How much should you pay?
Online direct-ship from REVXSC undercuts dealer parts counters significantly. We carry quality replacement differential pinion shims from Richmond Gear, USA Standard Gear, Yukon Gear, Motive Gear, Dana Spicer, Nitro Gear, Revolution Gear, Strange Engineering — every listing shows the price, the fitment chart, and real product photos. No mystery part numbers.
Featured differential pinion shims in stock right now
Shop all Differential Pinion Shim →
OEM vs aftermarket: which to choose
For differential pinion shims, the brand actually matters. Richmond Gear and USA Standard Gear supply major automakers as OEM suppliers — when you buy their boxed retail product, you're getting the same engineering and tolerances. Shims come in incremental thicknesses (typically 0.001-0.030 inch in 0.001 steps) and are sold individually or as shim packs covering the full range needed to dial in gear pattern..
Install: DIY or shop?
Difficulty: advanced. Bay time runs about 60–180 minutes with the right tools. Lifespan you should expect: indefinite once correctly set.
How REVXSC keeps prices low
Every listing includes a year/make/model/engine table.
ACDelco, Bosch, Dorman, Dayco, FEL-PRO and more.
Ships from US warehouses with real tracking.
No knockoff boxes, no rebranded junk.
Differential Pinion Shim shipping to every US state
REVXSC ships differential pinion shims same-day from US fulfillment to every state. Whether you're chasing salt-corroded differential pinion shims in the Midwest, heat-fatigued parts in the Southwest, or just need a fast OEM-grade replacement, every order ships from the US with tracking. We deliver to:
Common questions Americans ask about differential pinion shims
What does a pinion shim do?
The pinion shim sits between the pinion gear head and the inner pinion bearing and controls how deep the pinion meshes with the ring gear. Correct shim thickness gives a centered wear pattern; wrong thickness causes howl, premature wear, or gear failure.
How do you choose the right pinion shim?
Use the marking compound (gear marking paste) method: assemble with a starting shim, rotate the gears under light load, and read the pattern on the ring gear teeth. Pattern too close to the toe means shim too thin; too close to the heel means shim too thick.
How much does a pinion shim cost?
Individual shims cost $3-$15 each, and full shim packs covering 0.001-0.030 inch range cost $40-$120. Always have a complete pack on hand during a gear install because trial-and-error is required to dial the pattern.
How thick is a pinion shim?
Most pinion shims range from 0.020 to 0.040 inch total thickness, but they're built up from multiple smaller shims in 0.001-0.005 inch increments. The exact starting thickness comes from etch marks on the new pinion gear head.
Can I reuse the old pinion shim?
Only if you're installing the exact same gear set with identical pinion etch marks. New gears almost always require a different shim thickness because pinion-to-bearing distance varies slightly between gear sets.
What happens if pinion depth is wrong?
Wrong pinion depth causes the gear mesh to ride too high or too low on the tooth face. You'll hear a howl or whine that often varies between drive and coast, and the gears will pit or wear out within 10,000-30,000 miles.
Do I need a pinion depth tool to set pinion shim thickness?
A proper pinion depth tool ($150-$400) is the most precise method, but most gear installers use the trial-fit + marking compound method to verify the pattern, which works fine for street and most off-road builds.
How do I read a gear pattern?
Apply marking compound to several ring gear teeth, rotate the gears under load, and look at the pattern. Ideal pattern is centered top-to-bottom and lengthwise on each tooth, slightly biased toward the toe (small end) under drive load.
What's the difference between a pinion shim and a carrier shim?
Pinion shims set pinion gear depth (axial); carrier shims set carrier bearing preload and ring gear backlash (lateral). Both are required during a gear install and they affect each other.
